LPx 560/566 Memory Configurations
The computer comes with at least 8 MB of memory. This amount can be increased up to 128 MB, however,
when adding additional memory make sure to:
♦ Install 36-bit SIMMs having an access time of 70 ns or less.
♦ Fill two sockets at a time using the same SIMM size, type and speed.
Supported SIMM sizes: 4 MB, 8 MB, 16 MB, and 32 MB.
♦ Fill banks 0 and 1(marked A on the illustration) before banks 2 and 3 (marked B on the illustration).
Bank 0
Bank 1
Bank 2
Bank 3
Total
4 MB 4 MB
8 MB (standard)
4 MB 4 MB 4 MB 4 MB
16 MB
8 MB 8 MB
16 MB
4 MB 4 MB 8 MB 8 MB
24 MB
8 MB 8 MB 8 MB 8 MB
32 MB
16 MB 16 MB
32 MB
4 MB 4 MB 16 MB 16 MB
40 MB
8 MB 8 MB 16 MB 16 MB
48 MB
16 MB 16 MB 16 MB 16 MB
64 MB
32 MB 32 MB
64 MB
4 MB 4 MB 32 MB 32 MB
72 MB
8 MB 8 MB 32 MB 32 MB
80 MB
16 MB 16 MB 32 MB 32 MB
96 MB
32 MB 32 MB 32 MB 32 MB
128 MB
