Field
Description of fields within Register file: 0x12 Rx Frame Quality Information
CIR_PWR
reg:12:04
bits:3116
Channel Impulse Response Power. This is a 16-bit value reporting the sum of the squares of
the magnitudes of the accumulator from the estimated highest power portion of the channel,
which is related to the receive signal power. This value can be used in assessing the quality of
the received signal and/or the receive timestamp produced by the LDE algorithm. For more
details please refer to section 4.7 Assessing the quality of reception and the RX timestamp.
7.2.21 Register file: 0x13 Receiver Time Tracking Interval
ID
Length
(octets)
Type
Mnemonic
Description
0x13
4
ROD
RX_TTCKI
Receiver Time Tracking Interval- included in swinging set
Register map register file 0x13 operates with Register file: 0x14 Receiver Time Tracking Offset to give a
measure of the clock offset (or crystal offset) between the local receiver and the remote end transmitter
device.
Register file: 0x13 Receiver Time Tracking Interval is in the RX double-buffered swinging-set. See section
4.3 Double Receive Buffer for more details.
The RX_TTCKI register contains the following sub-fields which are updated when a frame demodulation is
completed successfully:
REG:13:00 RX_TTCKI Receiver Time Tracking Interval
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RXTTCKI
0
Field
Description of fields within Register file: 0x13 Receiver Time Tracking Interval
RXTTCKI
reg:13:00
bits:310
RX time tracking interval. The value here is the interval over which the timing offset reported
in the RXTOFS field of Register file: 0x14 Receiver Time Tracking Offset is measured. The clock
offset is calculated by dividing RXTOFS by RXTTCKI. The value in RXTTCKI will take just one of
two values depending on the PRF: 0x01F00000 @ 16 MHz PRF, and 0x01FC0000 @ 64 MHz
PRF.
7.2.22 Register file: 0x14 Receiver Time Tracking Offset
ID
Length
(octets)
Type
Mnemonic
Description
0x14
5
ROD
RX_TTCKO
Receiver Time Tracking Offset- included in swinging set
Register map register file: 0x14 operates with Register file: 0x13 Receiver Time Tracking Interval to give a
measure of the clock offset (or crystal offset) between the local receiver and the remote end transmitter
device.
