Page #12 background imageLoading...
Page #12 background image
Specification
057-086 ISSUE: 6
Page 12 of 56
2.7.3 MAGNETIC PICK-UP
NOTE: Only applicable to 3110-xxx-01 MPU/Hz variant.
Magnetic Pickup devices can often be ‘shared’ between two or more devices. For example, one
device can often supply the signal to both the DSE module and the engine governor. The possibility of
this depends upon the amount of current that the magnetic pickup can supply.
Description
Specification
Type
Single ended input, capacitive coupled
Minimum Voltage
0.5 V peak
Maximum Voltage
70 V peak
Max Common Mode Voltage
±2 V peak
Minimum Frequency
5 Hz
Maximum Frequency
10,000 Hz
Resolution
6.25 rpm
Accuracy
± 25 rpm
Flywheel Teeth
10 to 500
2.8 OUTPUTS
There are four outputs fitted to the controller
2.8.1 DC OUTPUTS A & B (FUEL & START)
NOTE: DC outputs A and B are fixed to Fuel and Start for the 3110-xxx-01 MPU/Hz variant,
they are only configurable with the 3110-xxx-02 CAN variant.
Description
Specification
Type
Supplied from Power Supply positive terminal.
Rating
2 A resistive continuous at 35 V
2.8.2 CONFIGURABLE DC OUTPUTS C AND D
Description
Specification
Type
Fully configurable, supplied from Power Supply positive terminal.
Rating
2 A resistive continuous at 35 V
2.9 COMMUNICATION PORTS
Description
Specification
USB Port
USB 2.0 Device for connection to PC running DSE configuration suite only.
Max distance 6 m (18 yards)
CAN Port
NOTE: Only applicable to 3110-xxx-02 CAN variant.
Engine CAN Port
Standard implementation of ‘Slow mode’, up to 250 kb/s.
Non-Isolated.
Internal Termination provided (120 )
Max distance 40 m (133 feet)
