4 DESCRIPTION OF CONTROLS
CAUTION: The module may instruct an engine start event due to external influences.
Therefore, it is possible for the engine to start at any time without warning. Prior to performing
any maintenance on the system, it is recommended that steps are taken to remove the battery
and isolate supplies.
NOTE: The following descriptions detail the sequences followed by a module containing
the standard ‘factory configuration’. Always refer to the configuration source for the exact
sequences and timers observed by any particular module in the field.
Control of the module is via push buttons mounted on the front of the module with
Stop/Reset Mode , Auto Mode and Manual/Start Mode functions. For normal operation,
these are the only controls which need to be operated. Details of their operation are provided later in
this document.
