6.2.3 DIGITAL INPUT SETTINGS
MPU/Hz
3110-xxx-01 (MPU/Hz) option only
CAN
3110-xxx-02 (CAN) option only
Configuration Parameters – Digital Inputs (Page 3)
301
Low Oil Pressure Enable
On (1), Off (0)
CAN
302
Low Oil Pressure Trip
0.00 Bar / PSI
CAN
303
High Engine Temperature Trip
0 ºC / ºF
CAN
304
Digital Input A Source
0 (Input Source)
305
Digital Input A Polarity
0 (Polarity)
306
Digital Input A Action (If Source = User Config)
0 (Action)
307
Digital Input A Arming (If Source = User Config)
0 (Arming)
308
RESERVED
309
Digital Input B Source
0 (Input Source)
310
Digital Input B Polarity
0 (Polarity)
311
Digital Input B Action (If Source = User Config)
0 (Action)
312
Digital Input B Arming (If Source = User Config)
0 (Arming)
313
RESERVED
314
Digital Input C Source
0 (Input Source)
315
Digital Input C Polarity
0 (Polarity)
316
Digital Input C Action (If Source = User Config)
0 (Action)
317
Digital Input C Arming (If Source = User Config)
0 (Arming)
318
RESERVED
0:00
319
Digital Input D Source
0 (Input Source)
320
Digital Input D Polarity
0 (Polarity)
321
Digital Input D Action (If Source = User Config)
0 (Action)
322
Digital Input D Arming (If Source = User Config)
0 (Arming)
323
RESERVED
0:00
324
Digital Input E Source
0 (Input Source)
325
Digital Input E Polarity
0 (Polarity)
326
Digital Input E Action (If Source = User Config)
0 (Action)
327
Digital Input E Arming (If Source = User Config)
0 (Arming)
328
RESERVED
0:00
329
Digital Input F Source
0 (Input Source)
330
Digital Input F Polarity
0 (Polarity)
331
Digital Input F Action (If Source = User Config)
0 (Action)
332
Digital Input F Arming (If Source = User Config)
0 (Arming)
6.2.4 OUTPUT SETTINGS
MPU/Hz
3110-xxx-01 (MPU/Hz) option only
CAN
3110-xxx-02 (CAN) option only
Configuration Parameters – Outputs (Page 4)
401
Digital Output A Source
0 (Output Source)
CAN
402
Digital Output A Polarity
0 (Output Polarity)
CAN
403
Digital Output B Source
0 (Output Source)
CAN
404
Digital Output B Polarity
0 (Output Polarity)
CAN
405
Digital Output C Source
0 (Output Source)
406
Digital Output C Polarity
0 (Output Polarity)
407
Digital Output D Source
0 (Output Source)
408
Digital Output D Polarity
0 (Output Polarity)
