3 INSTALLATION
The module is designed to be mounted on the panel fascia. For dimension and mounting details, see
the section entitled Specification, Dimension and mounting elsewhere in this document.
3.1 USER CONNECTIONS
NOTE: Availability of some terminals depends upon module version. Full details are given
in the section entitled Terminal Description elsewhere in this manual.
To aid user connection, numbers are used on the rear of the module to help identify terminal
functions. An example of this is shown below.
Terminals 1 to 7
Terminals 8 and 9
Terminals 10 to 17
USB PC
Configuration
Module Ratings
Module Part /
Serial Number
