DEEP SEA ELECTRONICS DSEGenset DSE3110 User Manual

Installation
Page 23 of 56
057-086 ISSUE: 6
3.2.3 MAGNETIC PICK-UP AND DIGITAL INPUTS (3110-XXX-01)
NOTE: For further details of module configuration, refer to DSE Publication: 057-087
DSE3110 DSE Configuration Suite PC Software Manual.
Pin
No
Description
Cable
Size
Notes
10
Magnetic Pickup Positive
0.5 mm²
AWG 20
Connect To Magnetic Pickup Device
11
Magnetic Pickup Negative
0.5 mm²
AWG 20
Connect To Magnetic Pickup Device
12
Configurable Digital Input A
0.5 mm²
AWG 20
Switch to DC Supply Negative
13
Configurable Digital Input B
0.5 mm²
AWG 20
Switch to DC Supply Negative
14
Configurable Digital Input C
0.5 mm²
AWG 20
Switch to DC Supply Negative
15
Configurable Digital Input D
0.5 mm²
AWG 20
Switch to DC Supply Negative
16
Configurable Digital Input E
0.5 mm²
AWG 20
Switch to DC Supply Negative
17
Configurable Digital Input F
0.5 mm²
AWG 20
Switch to DC Supply Negative
3.2.4 CAN AND DIGITAL INPUTS (3110-XXX-02)
NOTE: For further details of module configuration, refer to DSE Publication: 057-087
DSE3110 DSE Configuration Suite PC Software Manual.
NOTE: For further details on connection to electronic engines, refer to DSE Publication:
057-004 Electronic Engines And DSE Wiring
NOTE: Screened 120  impedance cable specified for use with CAN must be used for the
CAN link.
DSE stock and supply Belden cable 9841 which is a high quality 120  impedance cable
suitable for CAN use (DSE part number 016-030)
Pin
No
Description
Cable
Size
Notes
10
CAN Port H
0.5 mm²
AWG 20
Use only 120  CAN approved cable
11
CAN Port L
0.5 mm²
AWG 20
Use only 120  CAN approved cable
12
Configurable Digital Input A
0.5 mm²
AWG 20
Switch to DC Supply Negative
13
Configurable Digital Input B
0.5 mm²
AWG 20
Switch to DC Supply Negative
14
Configurable Digital Input C
0.5 mm²
AWG 20
Switch to DC Supply Negative
15
Configurable Digital Input D
0.5 mm²
AWG 20
Switch to DC Supply Negative
16
Configurable Digital Input E
0.5 mm²
AWG 20
Switch to DC Supply Negative
17
Configurable Digital Input F
0.5 mm²
AWG 20
Switch to DC Supply Negative
