DEEP SEA ELECTRONICS DSEGenset DSE3110 User Manual

Specification
057-086 ISSUE: 6
Page 18 of 56
2.12 APPLICABLE STANDARDS
Standard
Description
BS 4884-1
This document conforms to BS4884-1 1992 Specification for presentation
of essential information.
BS 4884-2
This document conforms to BS4884-2 1993 Guide to content
BS 4884-3
This document conforms to BS4884-3 1993 Guide to presentation
BS EN 60068-2-1
(Minimum temperature)
-30 C (-22 F)
BS EN 60068-2-2
(Maximum temperature)
+70 C (158 F)
BS EN 60068-2-6
(Vibration)
Ten sweeps in each of three major axes
5 Hz to 8 Hz at ± 7.5 mm
8 Hz to 500 Hz at 2 gn
BS EN 60068-2-27
(Shock)
Three shocks in each of three major axes
15 gn in 11 ms
BS EN 60068-2-30
(Damp heat cyclic)
20 °C to 55 °C at 95% relative humidity for 48 hours
BS EN 60068-2-78
(Damp heat static)
40 °C at 95% relative humidity for 48 hours
BS EN 60950
(Electrical safety)
Safety of information technology equipment, including electrical business
equipment
BS EN 61000-6-2
(Electro-magnetic
Compatibility)
EMC Generic Immunity Standard (Industrial)
BS EN 61000-6-4
(Electro-magnetic
Compatibility)
EMC Generic Emission Standard (Industrial)
BS EN 60529
(Degrees of protection
provided by enclosures)
IP65 (front of module when installed into the control panel with the
optional sealing gasket)
IP42 (front of module when installed into the control panel WITHOUT
being sealed to the panel)
UL508
NEMA rating
(Approximate)
12 (Front of module when installed into the control panel with the optional
sealing gasket).
2 (Front of module when installed into the control panel WITHOUT being
sealed to the panel)
IEEE C37.2
(Standard Electrical
Power System Device
Function Numbers and
Contact Designations)
Under the scope of IEEE 37.2, function numbers can also be used to
represent functions in microprocessor devices and software programs.
The controller is device number 11L-8000 (Multifunction device
protecting Line (generator) –module).
As the module is configurable by the generator OEM, the functions
covered by the module vary. Under the module’s factory configuration,
the device numbers included within the module are :
2 – Time Delay Starting Or Closing Relay
5 – Stopping Device
6 – Starting Circuit Breaker
8 – Control Power Disconnecting Device
11 – Multifunction Device
12 – Overspeed Device
14 – Underspeed Device
26 – Apparatus Thermal Device
Continued overleaf...

DEEP SEA ELECTRONICS DSEGenset DSE3110 Specifications

General

Brand	DEEP SEA ELECTRONICS
Model	DSEGenset DSE3110
Category	Control Unit
Language	English
