Page #22 background imageLoading...
Page #22 background image
Installation
057-086 ISSUE: 6
Page 22 of 56
3.2 CONNECTION DESCRIPTIONS
3.2.1 DC SUPPLY, DC OUTPUTS A TO D & CHARGE FAIL INPUT
NOTE: For further details of module configuration, refer to DSE Publication: 057-087
DSE3110 DSE Configuration Suite PC Software Manual.
NOTE: When the module is configured for operation with an electronic engine, FUEL and
START output requirements may be different. For further details on connection to electronic
engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring
Pin
No
Description
Cable
Size
Notes
1
DC Plant Supply Input
(Negative)
2.5 mm²
AWG 13
2
DC Plant Supply Input
(Positive)
2.5 mm²
AWG 13
Supplies the module and DC Outputs A, B, C & D
3
DC Output A (FUEL)
2.5 mm²
AWG 13
Plant Supply Positive from terminal 2.
2 A resistive continuous
Fixed as Fuel Relay for 3110-xxx-01 MPU/Hz variant.
Configurable for 3110-xxx-02 CAN variant.
4
DC Output B (START)
2.5 mm²
AWG 13
Plant Supply Positive from terminal 2.
2 A resistive continuous
Fixed as Start Relay for 3110-xxx-01 MPU/Hz variant.
Configurable for 3110-xxx-02 CAN variant.
5
DC Output C
1.0 mm²
AWG 18
Plant Supply Positive from terminal 2. 2 Amp rated.
6
DC Output D
1.0 mm²
AWG 18
Plant Supply Positive from terminal 2. 2 Amp rated.
7
Charge Fail / Excite
2.5 mm²
AWG 13
Do not connect to ground (battery negative).
If charge alternator is not fitted, leave this terminal disconnected.
3.2.2 GENERATOR VOLTAGE & FREQUENCY SENSING
NOTE: For further details of module configuration, refer to DSE Publication: 057-087
DSE3110 DSE Configuration Suite PC Software Manual.
NOTE: The below table describes connections to a three phase, four wire alternator. For
alternative wiring topologies, see the Alternate Topology Wiring Diagrams section of this
manual.
Pin
No
Description
Cable
Size
Notes
8
Generator Neutral (N) Input
1.0 mm²
AWG 18
Connect to generator neutral terminal.
9
Generator L1 (U) Voltage Input
1.0 mm²
AWG 18
Connect to generator L1 (U) terminal.
(Recommend 2 A fuse)
