Replacing the CPU board
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Place the CPU board on the CPU-board connector the system board.
2 Carefully, press down on the CPU board.
3 Align the screw holes on the CPU board with the screw holes on the
system board.
4 Replace the screws that secure the CPU board to the system board.
Post-requisites
1 Replace the heat sink.
2 Replace the memory module.
3 Follow step 2 to step 8 in “Replacing the back cover”.
