Replacing the riser card
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the bracket with the screw holes on the riser
card.
2 Replace the screws that secure the bracket with the riser card.
3 Insert the riser-card assembly in the riser-card slot.
4 Replace the screws that secure the riser-card assembly to the chassis.
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 9 in “Replacing the back cover”.
