Removing the CANbus card
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Follow step 1 to step 6 in “Removing the back cover”.
2 Remove the PCI/PCIe card (if installed).
Procedure
NOTE: Embedded Box PC is shipped with a combination of WWAN,
WLAN, and CANbus card depending on the configuration ordered.
1 Disconnect the CANbus cable from the connector on the CANbus card.
2 Remove the screws that secure the CANbus card to the system board.
