Replacing the back cover
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Replace the Replacing the hard-drive cage.
2 Insert the tabs on back cover at an angle into the slots on the chassis.
3 Open the back cover.
4 Route the SATA-power and SATA-data cables through the routing guides.
5 Connect the SATA-power and SATA-data cable to the hard drive or solid-
state drive assembly.
NOTE: Connect the cables to the second drive if installed.
6 Close the back cover.
7 Align the screw holes on the back cover with the screw holes on the
chassis.
8 Replace screws that secure the back cover to the chassis.
21
