Dell Embedded Box PC 5000 - Replacing the Canbus Cable; Procedure; Post-Requisites

Replacing the CANbus cable
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Place the CANbus port into the CANbus slot on the top cover.
2 Replace the hexagonal screws that secure the CANbus port to the top
cover.
3 Route the CANbus cable through the routing guides on the chassis and
under the heat sink plate.
4 Connect the CANbus cable to the connector on the CANbus card.
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 9 in “Replacing the back cover”.
