Replacing the heat sink
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Replace the thermal pads on the heat sink.
2 Place the heat sink on the CPU board.
3 Align the screw holes on the heat sink with the screw holes on the CPU
board.
4 In sequential order (indicated on the heat sink), replace the screws that
secure the heat sink to the CPU board.
5 Replace the screws that secure the chassis heat-sinks to the sides of the
chassis.
Post-requisites
1 Replace the riser card.
2 Replace the PCI/PCIe card (if necessary).
3 Follow step 2 to step 9 in replacing the “back cover”.
