Replacing the WLAN card
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
NOTE: To avoid damage to the WLAN card, do not place any cables
under it.
1 Align the notch on the WLAN card with the tab on the mPCIE2 slot.
2 Insert the WLAN card at an angle into the mPCIE2 slot.
3 Insert the WLAN-card bracket into the WLAN card.
4 Align the screw holes on the WLAN-card bracket with the screw holes on
the system board.
5 Replace the screws that secure the WLAN-card bracket to the system
board.
