Replacing the CANbus card
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the notch on the CANbus card with the tab on the mPCIE1 slot.
2 Insert the CANbus card at an angle into the mPCIE1 slot.
3 Align the screw holes on the CANbus card with the screw holes on the
system board.
4 Replace the screws that secure the CANbus card to the system board.
79
