3 Slide the SIM-card slot lock sway from the mPCIE1 connector to secure

the SIM-card slot.

1 SIM-card slot 2 SIM-card slot lock

3 SIM-card

Post-requisites

1 Replace the WWAN card.

2 Follow step 2 to step 9 in replacing the “back cover”.
