Removing the CANbus cable
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Follow step 1 to step 6 in “Removing the back cover”.
2 Remove the PCI/PCIe card (if installed).
Procedure
1 Disconnect the CANbus cable from the connector on the CANbus card.
2 Remove the CANbus cable from the routing guides on the chassis.
3 Slide the cable out from under the heat sink pipe.
4 Remove the hexagonal screws that secure the CANbus port to the top
cover.
