Replacing the serial ports
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Connect the serial-port cable to the connector on the system board.
2 Insert the serial ports into the respective slots on the bottom cover.
NOTE: Match the port number with the number on the cable.
3 Replace the hexagonal screws that secure the serial ports to the bottom-
cover.
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 9 in “Replacing the back cover”.
