Replacing the interposer board
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the interposer board with the screw holes on
the solid-state drive card bracket.
2 Replace the screws that secure the interposer board to the solid-state
drive card bracket.
Post-requisites
1 Replace the solid-state drive in to bracket.
2 Replace the drives in to the hard-drive cage.
3 Follow step 2 to step 8 in “Replacing the back cover”.
