Dell Embedded Box PC 5000 - Post-Requisites

5 Connect the CANbus cable to the connector on the CANbus card.
1 mPCIE1 slot 2 tab
3 notch 4 M2x3 screws (2)
5 system board 6 CANbus card
7 CANbus-card cable
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 9 in “Replacing the back cover”.
80
