Replacing the intrusion switch
WARNING: Before working inside your Embedded Box PC, read the
safety information that shipped with your Embedded Box PC and
follow the steps in
Before working inside your Embedded Box PC.
After working inside your Embedded Box PC, follow the steps in After
working inside your Embedded Box PC. For more safety best practices,
see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Replace the screw that secures the intrusion switch to the chassis.
2 Route the intrusion-switch cable through the routing guides on the
chassis and under the heat sink pipe.
3 Connect the intrusion-switch cable to the intrusion-switch connector on
the system board.
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 9 in “Replacing the back cover”.
