MIL 901E and MIL 461G rugged kit
The MIL 901E and MIL 461G rugged kit provides rugged protection for the PowerEdge XR12 server. The MIL 901E and MIL 461G
rugged kit consists of the components mentioned below:
● Power supply rugged bracket
●
Drive rugged bracket
● Nine countersunk screws
Topics:
• Installing the MIL 901E and MIL 461G rugged kit
Installing the MIL 901E and MIL 461G rugged kit
Prerequisites
NOTE: The MIL 901E and MIL 461G rugged kits are ordered separately from Dell.
1. Follow the safety guidelines listed in Safety instructions.
2. Unpack the 901E and MIL 461G rugged brackets.
3. Remove the front bezel for Front Accessed configuration.
4. Remove the system cover.
5. Remove the drive cage.
Steps
1. Using a Phillips #2 screwdriver, secure the power supply rugged bracket.
NOTE:
The kits consists of screws. Use three screws on the bottom side of the chassis and remaining three screws
above the bracket.
6
MIL 901E and MIL 461G rugged kit 121
