Dell PowerEdge XR12

Figure 40. Installing the expansion card riser 2
Next steps
1. Follow the procedure listed in After working inside your system.
2. Install any device drivers required for the card as described in the documentation for the card.
Removing the expansion card riser 3
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. Remove the expansion card riser 2.
4. Remove the air shroud.
5. Remove the drives.
6. Remove the backplane.
7. Remove the drive cage.
NOTE:
The procedure to remove the expansion card riser 3 is the same for Rear Accessed and Front Accessed
configurations.
Steps
1. Using Phillips #2 screwdriver, loosen the blue thumbscrews.
2. Hold the blue touch points and lift the expansion card riser from the riser connector on the system board.
44
Installing and removing system components
