Figure 86. Installing the intrusion switch module
Next steps
Follow the procedure listed in After working inside your system.
System memory
System memory guidelines
The PowerEdge XR12 system supports DDR4 registered DIMMs (RDIMMs), load reduced DIMMs (LRDIMMs) and Intel Optane
PMem 200 Series. System memory holds the instructions that are executed by the processor.
Your system contains 8 memory sockets organized into 8 channels to the processor.
Memory channels are organized as follows:
Table 27. Memory channels
Channel A Channel B Channel C Channel D Channel E Channel F Channel G Channel H
Slots A1 Slots A5 Slots A3 Slots A7 Slots A2 Slots A6 Slots A4 Slots A8
78 Installing and removing system components
