Bezel filter
Removing the bezel filter
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. Remove the bezel
Steps
Keep the bezel inside side facing up and slide the latch on either end of the bezel in the direction of the arrow. Now the latch is
opened, lift the filter by using the pull tab.
NOTE: To maintain optimal system health, Dell Technologies recommends checking and changing the filter every three
months. Filters can be ordered from Dell Technologies.
Figure 23. Removing the bezel filter for Rear Accessed configuration
Installing and removing system components
29
