Table 14. Configuration 0: R1B+R2A+R3A for Rear / Front Accessed configurations
Card type Slot priority Maximum number of cards
Internal PERC adapter (LP) 3 1
Dell External Adapter (FH) 2, 4 2
GPU (FH) 4, 2 2
Mellanox (NIC: 100Gb) (FH) 4, 2 2
Mellanox (NIC: 25Gb) (FH) 4, 2 2
Broadcom (NIC: 25Gb) (FH) 4, 2 2
Broadcom (NIC: 25Gb) (LP) 3 1
Broadcom (NIC: 10Gb) (FH) 4, 2 2
Broadcom (NIC: 10Gb) (LP) 3 1
Broadcom (NIC: 1Gb) (FH) 4, 2 2
Broadcom (NIC: 1Gb) (LP) 3 1
Intel (NIC: 25Gb) (FH) 4, 2 2
Intel (NIC: 25Gb) (LP) 3 1
Intel (NIC: 4x10Gb SFP+) (FH) 2 1
Intel (NIC: 2x10Gb SFP+) (FH) 2 1
Intel (NIC: 10Gb) (FH) (all others
including V2 of 4x10 and 2x10 SFP+
cards)
4, 2 2
Intel (NIC: 10Gb) (LP) 3 1
Intel (NIC: 1Gb) (FH) 4, 2 2
Intel (NIC: 1Gb) (LP) 3 1
Dell BOSS S1 card Module Integrated slot 1
Table 15. Configuration 1: R1B+R2B+R3B Rear / Front Accessed configurations
Card type Slot priority Maximum number of cards
Internal PERC adapter (LP) 3 1
Dell External Adapter (FH) 1, 2, 4, 5 2
Broadcom (NIC: 25Gb) (FH) 4, 5, 2, 1 4
Broadcom (NIC: 25Gb) (LP) 3 1
Broadcom (NIC: 10Gb) (FH) 4, 5, 2, 1 4
Broadcom (NIC: 10Gb) (LP) 3 1
Broadcom (NIC: 1Gb) (FH) 4, 5, 2, 1 4
Broadcom (NIC: 1Gb) (LP) 3 1
Intel (NIC: 25Gb) (FH) 4, 5, 1, 2 4
Intel (NIC: 25Gb) (LP) 3 1
Intel (NIC: 4x10Gb SFP+) (FH) 1, 2 2
Intel (NIC: 2x10Gb SFP+) (FH) 1, 2 2
Installing and removing system components 39
