5 Push
the
new device
into the
bay
until it clicks.
6
If
you removed a device security screw
in
step 1, replace
it.
Hinge
Cover
CAUTION:
Before you begin any of the procedures
in
this section,
follow
the safety instructions
in
the
Product
Information
Guide
.
NOTICE:
To
avoid electrostatic discharge, ground yourself by using
a
wrist grounding strap or by
periodically
touching an unpainted metal surface (such as
a
connector on the back of the
computer).
NOTICE:
The hinge cover is fragile and can be damaged
if
extreme force is used. Be careful when removing
the
hinge
cover
.
1 Follow
the
procedures
in
"Before You Begin" on page
107.
2
Turn the
computer top-side up, and then open
the
display
all the
way (180 degrees) so
that it
rests
on
your work
surface.
NOTICE:
To avoid damaging the hinge cover, do not
lift
the cover on both sides
simultaneously
.
3 Insert a scribe
in the
indent
to
carefully pry
up the
hinge cover on
the right side.
112
Adding and Replacing
Parts
