Installing the keyboard
1 Align the keyboard and route the cables back through to the bottom of the compartment.
2 Press and align the keyboard to its compartment.
3 Replace the screws to secure the keyboard to the computer.
4 Slide the keyboard trim and align it to its position on the computer. Ensure that the keyboard trim clicks into its place
5 Connect the keyboard data cables to the touchpad board.
NOTE
: Ensure that you fold the keyboard data cable in perfect alignment.
6 Ax the tape on the keyboard data cables.
7 Install the:
a hard drive
b battery
c battery cover
8 Follow the procedure in After working inside your computer.
Base cover
Removing the base cover
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a battery cover
b battery
3 To remove base cover:
a Remove the M2.5X5.0 screws that secure the base cover to the computer [1].
b Slide and lift the base cover away from the computer [2].
Disassembly and reassembly
15
