Installing the display panel
NOTE: For touch systems perform following steps.
1 To install the display panel for touch systems:
a Place the display panel on a at surface.
b Connect the eDP and display cables to the connector on the back of the display panel and ax the adhesive tape.
c Turn the display assembly over.
d Align the display panel with the tabs on the display assembly.
e Press the edges of the display panel to secure it to the display assembly.
2 Install the:
a display bezel
b display assembly
c palmrest
d keyboard
e hard drive
f base cover
g battery
h battery cover
3 Follow the procedure in After working inside your computer.
Display bracket
Removing the display bracket
NOTE
: For non touch systems perform following steps.
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a battery cover
b battery
c base cover
d hard drive
e keyboard
f palmrest
g display assembly
h display bezel
i display panel
3 To remove display bracket:
a Remove the M2.5x4.0 screws that secure display cover [1].
b Remove the display brackets from the display cover [2].
