Dell Precision 7520 - Installing the Edp Cable; Camera; Removing the Camera

Installing the eDP cable
NOTE: For non touch systems perform following steps.
1 Route the eDP cable on the display cover.
2 Ax the eDP cable on the display cover.
3 Install the:
a display panel
b display bezel
c display assembly
d palmrest
e keyboard
f hard drive
g base cover
h battery
i battery cover
4 Follow the procedure in After working inside your computer.
Camera
Removing the camera
NOTE
: For non touch systems perform following steps.
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a battery cover
b battery
c base cover
d hard drive
e keyboard
f palmrest
g display assembly
h display bezel
3 To remove camera:
a Peel the eDP cable and disconnect the camera cable from the computer [1].
b Lift the camera module from the computer [2].
52
Disassembly and reassembly
