Installing the M.2 SSD module
1 Place the SSD in its slot.
2 Replace the M2.0x3.0 screw to secure the SSD to the computer.
3 Place the thermal plate on the SSD.
4 Replace the M2.0x3.0 screw to secure the thermal plate to the computer.
5 Install the:
a base cover
b battery
c battery cover
6 Follow the procedure in After working inside your computer.
Coin-cell battery
Removing the coin cell battery
1 Follow the procedures in Before working inside your computer.
2 Remove the:
a battery cover
b battery
c base cover
3 To remove coin cell battery:
a Disconnect the coin cell battery cable from the computer [1].
b Pry and lift the coin cell battery from the computer [2].
22
Disassembly and reassembly
