Installing the base cover
1 Slide the base cover to align with the screw holes on the computer.
2 Replace the M2.5X5.0 screws to secure the base cover to the computer.
3 Install the:
a battery
b battery cover
4 Follow the procedure in After working inside your computer.
SIM card
Removing the SIM card
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a battery cover
b battery
c base cover
3 To remove the SIM card press in on the card to release.
NOTE
: During installation or removal of the SIM card, always ensure all data is backed up properly.
16 Disassembly and reassembly
