121
NOTICE: Do not route card cables over or behind the cards. Cables routed over the cards can
prevent the computer cover from closing properly or cause damage to the equipment.
8
Connect any cables that should be attached to the card.
See the documentation for the card for information about the card’s cable
connections.
NOTICE: To connect a network cable, first plug the cable into the network wall jack and then
plug it into the computer.
9
Close the computer cover, reconnect the computer and devices to electrical outlets,
and turn them on.
10 If you installed a sound card:
1 base
2 AGP retention spring
3 indentation
