30 About Your Computer—Dell Precision 450
www.dell.com | support.dell.com
Back View
Back Panel Connectors
12
345
1 cover release latch Push the latch to the left to open the computer cover.
2 padlock ring Insert a padlock to lock the computer cover.
3 power connector Insert the power cable.
4 card slots (4) Access connectors for any installed PCI and AGP cards.
5 back panel connectors Plug serial, USB, and other devices into the appropriate connector.
1234
13 12 11 10 9 8
567
