Drives 137
4 Gently slide the drive into place until the tabs securely click into position.
NOTE: If you are installing a hard drive in the lower bay, the drive should be placed in the bay
so that the power connector is on the left-hand side (opposite of the top hard drive).
1 drive
2 bracket rails (2)
3 screws (4)
1
3
2
