Drives 153
7 If you are installing a new CD/DVD drive rather than replacing a drive, remove the
front-panel inserts.
From inside the drive bay, gently press on each side of the insert until it pops out.
1 audio cable (some drives
do not have this cable)
2 CD/DVD drive cable
3 power cable
2
3
1
