About Your Computer—Dell Precision 650 23
Cable Colors
1 floppy drive 5 padlock ring
2 CD/DVD drive 6 microprocessor airflow shroud
3 hard drive 7 system board
4 power supply 8 chassis intrusion switch
Device Cable Color
Hard drive Blue pull tab
Floppy drive Black pull tab
CD/DVD drive Orange pull tab
