8. Follow the procedure in after working inside your computer.
Power button with optional fingerprint reader
Removing the power button with an optional fingerprint reader
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card.
3. Remove the base cover.
4. Remove the 5G WWAN card.
5. Remove the M.2 2230 or M.2 2280 SSD.
6. Remove the battery.
7. Remove the system board.
NOTE: The system board can be removed and installed with the heat sink attached in order to simplify the procedure
and preserve the thermal bond between the system board and heat sink.
About this task
The following images indicate the location of the power button with an optional fingerprint reader and provide a visual
representation of the removal procedure.
Figure 54. Removing the power button with an optional fingerprint reader
