12. Place the WLAN bracket to the palm-rest assembly.
13. Replace the screw (M2x2.5) that secure the WLAN bracket to the palm-rest assembly.
Next steps
1. Install the heat sink
2. Install the speakers
3. Install the 5G WWAN card
4. Install the M.2 2230 or M.2 2280 SSD.
5. Install the Install M.2 2230 or M.2 2280 base cover.
6. Install the SIM card.
7. Follow the procedure in After working inside your computer
USB-C connector module
Removing the USB- C connector module
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the sim-card tray, if applicable.
3. Remove the base cover.
4. Remove the system board.
5. Remove the M.2 2230 or M.2 2280 SSD, as applicable
6. Remove the 5G WWAN card.
7. Remove the Speakers
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
Figure 52. Removing the USB-C Connector Module
Removing and installing Field Replaceable Units (FRUs)
101
