Table 9. Wireless module specifications(continued)
Description Values
Wireless standards
● WiFi 802.11a/b/g
● Wi-Fi 4 (WiFi 802.11n)
● Wi-Fi 5 (WiFi 802.11ac)
● Wi-Fi 6E (WiFi 802.11ax)
● Wi-Fi 7 (WiFi 802.11be)
Encryption
● 64-bit/128-bit WEP
● AES-CCMP
● TKIP
Bluetooth wireless card
Bluetooth 5.4
WWAN module
The following table lists the Wireless Wide Area Network (WWAN) module that is supported in your Dell Pro 16 Plus.
NOTE: The WWAN module is available only on certain configurations and in certain regions.
NOTE: Availability of the eSIM feature on this module depends your region.
NOTE: For instructions on how to setup SIM or eSIM connections on your computer, see the SIM/eSIM Setup Guide for
Windows available with your product documentation at Dell Support Site.
Table 10. WWAN module specifications
Description Values
Model number DW5933e MediaTek T700 Global 5G Modem
Form factor M.2 3052 Key-B
Host interface PCIe Gen3
Network standard NR FR1(Sub6) FDD/TDD, LTE FDD/TDD, WCDMA/HSPA+,
GPS/GLONASS/Galileo/BDS/QZSS
Transfer data rate
SA: DL 4.67Gbps/ UL 1.25Gbps
NSA: DL 3.74Gbps/ UL 835Mbps
LTE: DL 1.6Gbps (CAT19)/ UL 211Mbps
UMTS: DL384 kbps/ UL 384 kbps
DL DC-HSPA+:42 Mbps (CAT24)/ UL 11.5 Mbps (CAT7)
Operating frequency bands
● LTE (1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28,
29, 30, 32, 34, 38, 39, 40, 41, 42, 43, 46, 66, 71)
● NR (1, 2, 3, 5, 7, 8, 20, 25, 28, 38, 40, 41, 48, 66, 71, 77,
78, 79)
● HSPA+ (1, 2, 4, 5, 8)
Power supply DC 3.135 V to 4.4 V, Typical 3.3 V
SIM card Supported through external SIM slot
NOTE: The availability of eSIM functionality embedded on
the module is dependent on the region and specific carrier
requirements.
eSIM with dual SIM (DSSA) Supported
Antenna diversity Supported
Specifications of Dell Pro 16 Plus 17
