Steps
1. Remove the M2x3 screw that secures the fingerprint reader bracket to the system board.
2. Remove the two (M2x3) screws that secure the display-cable bracket to the system board.
3. Lift the display-cable bracket off the palm-rest assembly.
4. Disconnect the display cable from the display cable connector (LCD1) on the system board.
5. Remove the display cable from the routing guides on the system board.
6. Lift the black flap near the antenna cables to uncover the sensor-board cable.
7. Disconnect the sensor-board cable from the connector on the system board.
8. Remove the antenna cables (where applicable) from the routing guides on the system board.
9. Remove the six screws (M2.5x5) that secure the left and right display hinges to the palm-rest assembly.
10. Carefully lift the display assembly from the palm-rest assembly.
11. Carefully place the display assembly on a clean, flat surface.
Installing the display assembly
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the installation
procedure.
66
Removing and installing Field Replaceable Units (FRUs)
