Field Description
• Internally propagated: ETS configuration
parameters were received from configuration
source.
ETS DCBx Oper status Operational status of ETS configuration on local
port: match or mismatch.
State Machine Type Type of state machine used for DCBx exchanges of
ETS parameters:
• Feature: for legacy DCBx versions
• Asymmetric: for an IEEE version
Conf TLV Tx Status Status of ETS Configuration TLV advertisements:
enabled or disabled.
ETS TLV Statistic: Input Conf TLV pkts Number of ETS Configuration TLVs received.
ETS TLV Statistic: Output Conf TLV pkts Number of ETS Configuration TLVs transmitted.
ETS TLV Statistic: Error Conf TLV pkts Number of ETS Error Configuration TLVs received.
The following example shows the show stack-unit all stack-ports all pfc details
command.
Dell(conf)# show stack-unit all stack-ports all pfc details
stack unit 1 stack-port all
Admin mode is On
Admin is enabled, Priority list is 4-5
Local is enabled, Priority list is 4-5
Link Delay 45556 pause quantum
0 Pause Tx pkts, 0 Pause Rx pkts
stack unit 2 stack-port all
Admin mode is On
Admin is enabled, Priority list is 4-5
Local is enabled, Priority list is 4-5
Link Delay 45556 pause quantum
0 Pause Tx pkts, 0 Pause Rx pkts
The following example shows the show stack-unit all stack-ports all ets details
command.
Dell(conf)# show stack-unit all stack-ports all ets details
Stack unit 1 stack port all
Max Supported TC Groups is 4
Number of Traffic Classes is 1
Admin mode is on
Admin Parameters:
--------------------
Admin is enabled
TC-grp Priority# Bandwidth TSA
------------------------------------------------
0 0,1,2,3,4,5,6,7 100% ETS
1 - -
2 - -
3 - -
4 - -
278
Data Center Bridging (DCB)
