Delta Electronics DVP15MC11T User Manual

Chapter 8 Logic Instructions
8_
 Precautions for Correct Use

The input variables are not allowed to omit. An error will occur during the compiling of the software if
any input variable is omitted. But the output variable is allowed to omit.

The data type of output variables must be BOOL. Otherwise, an error will occur during the compiling
of the software.

Programming Example

The data types of LE_In1, LE_In2 and LE_In3 are INT, UINT and DINT respectively and the
data type of Out1 is BOOL.
Out1 changes to TRUE when the values of LE_In1, LE_In2 and LE_In3 are -10, 50 and 50
respectively and LE_EN changes to TRUE as shown in Variable 1.
Out1 changes to FALSE when the values of LE_In1, LE_In2 and LE_In3 are 20, 10 and 100
respectively and LE_EN changes to TRUE as shown in Variable 2.
 Variable 1
Variable name Data type Current value
LE_EN BOOL TRUE
LE_In1
INT
-10
LE_In2
UINT
50
LE_In3
DINT
50
Out1
BOOL
TRUE
 Variable 2
Variable name
Data type
Current value
LE_EN
BOOL
TRUE
LE_In1
INT
20
LE_In2
UINT
10
LE_In3
DINT
100
Out1 BOOL FALSE
 The Program

The data types of LE_In1 and LE_In2 are both TIME and the data type of Out1 is BOOL.
Out1 changes to TRUE when the values of LE_In1 and LE_In2 are T#1ms and T#50ms respectively
and LE_EN is TRUE.
 The variable table and program
Variable name
Data type
Current value
LE_EN
BOOL
TRUE
LE_In1 TIME T#1ms
LE_In2 TIME T#50ms
Out1 BOOL TRUE
1
LE
EN ENO
In1 Out
In3
In2
LE_EN
LE_In1
LE_In3
LE_In2
Out1
1
LE
EN ENO
In1 Out
In2
LE_EN
LE_In1
LE_In2
Out1
8-31
