DVP15MC11T Operation Manual
_8
Data type
The value of In corresponds to the value of Out
In
Out
In
Out
UDINT
16#****_****_0000_0000~
16#****_****_FFFF_FFFF
0~4294967295
ULINT
16#0000_0000_0000_0000~
16# FFFF_FFFF_FFFF_FFFF
0~18446744073709551645
SINT
16#****_****_****_**00~
16#****_****_****_**7F
0~127
16#****_****_****_**80~
16#****_****_****_**FF
-128~-1
INT
16#****_****_****_0000~
16#****_****_****_7FFF
0~32767
16#****_****_****_8000~
16#****_****_****_FFFF
-32768~-1
DINT
16#****_****_0000_0000~
16#****_****_7FFF_FFFF
0~2147483647
16#****_****_8000_0000~
16#***_*****_FFFF_FFFF
-2147483648~-1
LINT
16#0000_0000_0000_0000~
16#7FFF_FFFF_FFFF_FFFF
0~9223372036854775807
16#8000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
-9223372036854775808~0

Bit string to Real number
 The Bit-string data can be converted to the Real-number data. And some instructions are
shown below.
 The Bit-string data are converted into the Real-number data as the following table shows.
Data type
The value of In corresponds to the value of Out
In
Out
In
Out
BYTE
REAL
16#00~16#FF
0~2.55e+2
LREAL
16#00~16#FF
0~2.55e+2
WORD
REAL
16#0000~16#FFFF
0~6.5535e+4
LREAL
16#0000~16#FFFF
0~6.5535e+4
DWORD
REAL
16#0000_0000~
16#FFFF_FFFF
0~4.294967e+9
LREAL
16#0000_0000~
16#FFFF_FFFF
0~4.294967295e+9
LWORD
REAL
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
0~1.844674e+19
LREAL
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
0~1.84467440737095e+19
BYTE_TO_REAL
EN ENO
Out
In
BYTE_TO_LREAL
EN ENO
Out
In
LWORD_TO_REAL
EN ENO
OutIn
LWORD_TO_LREAL
EN ENO
OutIn
8-156
