DVP15MC11T Operation Manual
11
1
Direction: 1 (Positive direction)
Current position: 315°
Target position: 90°
Movement angle: 135°
Direction: 3 (Negative direction)
Current position: 315°
Target position: 90°
Movement angle: 225°
Direction: 2 (Shortest way)
Current position: 315°
Target position: 90°
Movement angle: 135°
Direction: 2 (Shortest way)
Current position: 315°
Target position: 270°
Movement angle: 45°
Direction: 4 (Current direction)
The status of the rotary axis before the instruction is
executed: Moving in the negative direction.
Current position: 315°
Target position: 90°
Movement angle: 225°
Direction: 4 (Current direction)
The status of the rotary axis before the
instruction is executed: motionless or moving
in the positive direction.
Current position: 315°
Target position: 90°
Movement angle: 135°
11-56
