DVP15MC11T Operation Manual
Timing for changing to TRUE
Timing for changing to FALSE
Busy
When Execute changes to TRUE.
When Done changes to TRUE.
When Error changes to TRUE.
Error
When an error occurs in the
instruction execution or the input
parameters for the instruction are
illegal.
When Execute changes from
TRUE to FALSE.
Function
Before the rotary-cut relationoship is established, the instruction is used for initializing the radius of the
rotary-cut axis and feed axis, cutting length, SYNC area and other parameters. After the instruction
execution succeeds, relevant parameters will be downloaded so as to call for use in the established
rotary-cut relationship.
After the rotary-cut relationship is established, the instruction can be used to modify the rotary-cut
parameters. After the instruction execution is completed, the new parameters will be taken into effect in
the next cycle.
11-184
