Appendix A. Modbus Communication
A_
Note:
The value of Byte 2 in the response message is determined by the values of Byte 4 and Byte 5
in the request message. For example, the number of the read bit registers in request message
is A. Dividing A by 8 produces B. If the quotient is an integer, the number of bytes of bit
registers in the response message is B. Otherwise the number of bytes will be B+ 1.
See the example below for details.
 Example
Read the state value of %QX2.0~%QX3.4 in DVP15MC11T via function code 02. The address
of %QX2.0 is 0xA010. Suppose %QX2.0~%QX2.7=1000 0001, %QX3.0~%QX3.4=1 0001.
Request message: 01 02 A0 10 00 0D 9A 0A
Response message: 01 02 02 81 11 19 E4
 Function code 0x05 writes one single bit register value
 Data structure of a request message:
Byte NO. Name Byte
Byte0
Modbus ID
Single byte
Byte1
Function code
Single byte
Byte2
Modbus address of the bit register
High byte
Byte3 Low byte
Byte4
The value written in the bit register
High byte
Byte5 Low byte
Byte6
Low byte of CRC check sum
Low byte
Byte7
High byte of CRC check sum
High byte
 Data structure of a response message:
Byte NO. Name Byte
Byte0
Modbus ID
Single byte
Byte1
Function code
Single byte
Byte2
Modbus address of the bit register
High byte
Byte3 Low byte
Byte4
The value written in the bit register
High byte
Byte5 Low byte
Byte6
Low byte of CRC check sum
Low byte
Byte7
High byte of CRC check sum
High byte
A-13
