 Data structure of an exception response message:
Byte NO. Name Byte
Byte0 Modbus ID
Single byte
Byte1 0x80+ Function code
Single byte
Byte2 Exception response code
Single byte
Byte3
Low byte of CRC check sum
Low byte
Byte4
High byte of CRC check sum
High byte
Note: The written value 0x0000 for the bit register in request message or response message
indicates the value FALSE is written in the bit register; the written value 0xFF00 for the bit
register indicates the value TRUE is written in the bit register.
 Example
The value of %QX0.0 in DVP15MC11T is set to TRUE and the address of %QX0.0 is set to
0xA000 via function code 05.
Request message: 01 05 A0 00 FF 00 AE 3A
Response message: 01 05 A0 00 FF 00 AE 3A
 Function code 0x0F writes multiple bit register values
 Data structure of a request message:
Byte NO. Name Byte
Byte0
Modbus ID
Single byte
Byte1
Function code
Single byte
Byte2
The start address of the bit registers where to write values
High byte
Byte3 Low byte
Byte4
The number of bit registers where to write values
High byte
Byte5 Low byte
Byte6 The number of bytes of bit registers where to write values
Single byte
Byte7 The value written to the bit register
Single byte
… The value written to the bit register
Single byte
Byte n The value written to the bit register
Single byte
Byte n+1
Low byte of CRC check sum
Low byte
Byte n+2
High byte of CRC check sum
High byte
A-14
